CBSE Class 11 Maths Notes Chapter 11 Conic Sections

Conic Sections Class 11 Notes Chapter 11

Circle
A circle is the set of all points in a plane, which are at a fixed distance from a fixed point in the plane. The fixed point is called the centre of the circle and the distance from centre to any point on the circle is called the radius of the circle.
The equation of a circle with radius r having centre (h, k) is given by (x – h)² + (y – k)² = r².

The general equation of the circle is given by x² + y² + 2gx + 2fy + c = 0 , where, g, f and c are constants.

• The centre of the circle is (-g, -f).
• The radius of the circle is r = \(\sqrt { { g }^{ 2 }+{ f }^{ 2 }-c }\)

The general equation of the circle passing through origin is x² + y² + 2gx + 2fy = 0.

The parametric equation of the circle x² + y² = r² are given by x = r cos θ, y = r sin θ, where θ is the parametre and the parametric equation of the circle (x – h)² + (y – k)² = r² are given by x = h + r cos θ, y = k + r sin θ.

Note: The general equation of the circle involves three constants which implies that at least three conditions are required to determine a circle uniquely.

Conic Sections Class 11 Formulas Chapter 11

Parabola
A parabola is the set of points P whose distances from a fixed point F in the plane are equal to their distance from a fixed line l in the plane. The fixed point F is called focus and the fixed line l is the directrix of the parabola.

Main Facts About the Parabola

Forms of parabola	y2= 4ax	y2 = -4ax	x2 = 4ay	x2 = -4ay
Axis of parabola	y = 0	y = 0	x = 0	x = 0
Directrix of parabola	x = -a	x = a	y = -a	y = a
Vertex	(0, 0)	(0, 0)	(0, 0)	(0, 0)
Focus	(a, 0)	(-a, 0)	(0, a)	(0, -a)
Length of latus rectum	4a	4a	4a	4a
Focal length	|x + a|	|x – a|	|y + a|	|y – a|

Class 11 Conic Section Notes Chapter 11

Ellipse
An ellipse is the set of all points in a plane such that the sum of whose distances from two fixed points is constant.
or
An ellipse is the set of all points in the plane whose distances from a fixed point in the plane bears a constant ratio, less than to their distance from a fixed point in the plane. The fixed point is called focus, the fixed line a directrix and the constant ratio(e) the eccentricity of the ellipse. We have two standard forms of ellipse i.e.

Main Facts about the Ellipse

Conic Sections Formulas Class 11 Chapter 11

Hyperbola
A hyperbola is the locus of a point in a plane which moves in such a way that the ratio of its distance from a fixed point in the same plane to its distance from a fixed line is always constant which is always greater than unity. The fixed point is called the focus, the fixed line is called the directrix and the constant ratio, generally denoted bye, is known as the eccentricity of the hyperbola.
We have two standard forms of hyperbola i.e.

Main Facts About Hyperbola
